Baseboard BL i.MX8M MINI
Baseboard BL i.MX8M Mini with High-Performance Processor Quad Core 1.6 GHz
Specifications
- NXP i.MX8M Mini 4x Arm® Cortex®-A53 @1.6 GHz and 1x Arm® Cortex-M4 @400 MHz with various interfaces
- LPDDR4-RAM 1 GByte/up to 4 GByte, NOR-Flash 2 MByte, eMMC 4 GByte/up to 64 GByte
- Ethernet, USB, Serial, CAN, DIO, LCD interface
- Powered by Embedded Linux (Yocto Distribution)
Features
| CPU | NXP i.MX8M Mini 4x Arm® Cortex®-A53 @1.6 GHz, 1x Arm® Cortex®-M4 @400 MHz, 2D GPU and 3D GPU |
| LPDDR4-RAM | 4 GByte Options: 1 GByte / 2 GByte |
| NOR-FLASH | 2 MByte |
| eMMC | 32 GByte Option: 4 GByte / 64 GByte |
| SD CARD | 1x micro-SD Slot |
| NV MEMORY | 64kbit EERAM |
| Ethernet | 1x 1 Gbit/s, 1x 10/100 Mbit/s |
| USB | 2x 2.0 Host, 1x 2.0 OTG |
| DIO | 4x DIO (24 V/up to 800 mA) |
| Serial | 1x RS232, 1x RS485 |
| CAN | 1x CAN 2.0 B |
| LCD INTERFACE | 1x HDMI, 1x LVDS, up to 1920 x 1080 @60fps |
| Touch | 1xI²C, 1x USB |
| Power Supply | 24 V DC ±20 % |
| Power Consumption | Linux running < 3 W |
| Temperature range | 0 °C...+70 °C |
| Operating System | Embedded Linux (Yocto Distribution) |
| Form Factor | 105,5 x 67 mm (4,3”) |
| RTC | 5ppm accuracy |
| RTC BUFFERING | CR1220 |
| Expansion Plugs | 1x I²C, 1x PCIe, 1x SPI, 1x SDIO 8 bit, 1x QSPI, 1x SAI, 1x USB Camera Interface 1x MIPI CSI (4-lane) |
| Audio | 1x Buzzer |
| Security | HAB Secure Boot, TrustZone, True RNG, RSA up to 4096, AES-128/192/256, 3DES, ARC4, MD-5, SHA up to 256, ECC, Secure JTAG |
