VX3030 Dieses Produkt ist Legacy
3HE VPX Intel® Core™ i7 Single Board Computer
Spezifikationen
- Neue Mikroarchitektur - VPX SBC mit Quad-Thread-Execution # Intel® Dual-Core™ Core i7 mit integriertem DDR3 Speicher-Controller # Zwei Cores mit Hyperthreading (4 Threads insgesamt) von 1,67 GHz bis 2 GHz # Unterstützt bis zu 8 GB Dual-Channel DDR3 SDRAM mit 1066 MHz und ECC # Und mehr…
3HE VPX Intel® Core™ i7 Single Board Computer
Der VX3030 ist ein multifunktioneller und robuster 3HE VPX Single Board Computer mit der ultimativen Performance für Embedded Applikationen. In Verbindung mit der Kontrons Long Term Supply Programm präsentiert sich der Kontron VX3030 als der multifunktionale, kompakte SBC für Generationen von Embedded Applikationen in den Märkten und Luftfahrt. In Kontrons 3HE Entwicklungssystemen ist der VX3030 zusammen mit 3HE VPX Carrierboards und VPX Ethernet Switchen die ideale Lösung für Langzeitprojekte, die nach multifunktionalen, kompakten und leistungsfähigen Parallel-Computing Lösungen suchen.
Eigenschaften
| CPU | Intel® Core™ i7 processor with integrated memory and graphics controller supporting ECC |
| SRAM | Two DDR3 memory channels, 64-bit soldered ECC |
| BIOS | Two sites up to 32 MB SPI Flash |
| Controller | Intel Platform Controller Hub PCH QM57 (Ibex Peak-M) |
| Rear I/O | Gigabit Ethernet: Two 1000BASE-BX and one 1000BASE-T; 4 SATA ports allowing Raid storage support; PCI Express: one x4 or four x1 PCI Express interfaces on VPX P1 (x4 Pipes Region) (Optional common PCIe reference clock feature); 2 Serial Ports: two simplified serial lines or other build options (two Rx/Tx ports on each node is default); DisplayPort: Embedded DisplayPort on VPX P2 |
| Frontpanel | Gigabit Ethernet: One 1000BASE-T on RJ-45 connector; Graphics: VGA; USB : USB 2.0 port;Serial Port: one EIA-232 UART interface on RJ11 connector; LEDs: three control and status bicolor (red/green) LEDs |
| Power Supply | 12V & 5V payload power, 3.3V auxiliary management power: 50W* with 4 GB of memory, no RTM Max of 65W; * The power consumption varies depending on your product configuration (Clock settings, XMC, RTM & extra memory) |
| PCI Express / PCI support | 2.5 GT/s gen 1 PCIe. One 4x PCIe to the backplane x4 pipes through PEX8609 Non Transparent bridge. |
| Verified OS | Linux: Generic Linux 2.6.x BSP to be used with various Linux distributions. Verified for RedHat 5.3 and Wind River Linux (PNE 3.x); Windows XP, Windows7; VxWorks 6 |
Downloads
Datasheets
VX3030 Datasheet
[ vx3030-ds.pdf, 1.87 MB, Aug.31.2017 ]
VME-VPX shortform catalog
[ shortform-vme-vpx.pdf, 1.36 MB, Jun.18.2024 ]
Kontron Modular Computers S.A.S. Service and Support Offering
This data sheet contains a detailed description of all the support and service offering from Kontron Modular Computers S.A.S, including the Long Term Supply (LTS) Services.
[ support-brochure-03-2018.pdf, 894.71 KB, Jun.28.2018 ]
Manuals
VX3030 - 3U VPX Computing Node User's Guide
[eingeschränkter Download]
[ cadta87-6e-vx3030-ug.pdf, 3.41 MB, Sep.11.2017 ]
VX3030 AMI-BIOS User Reference Manual
[eingeschränkter Download]
[ sddtf81-9e-vx3030-bios.pdf, 5.47 MB, Sep.11.2017 ]
VX3030 PBIT User's Guide
[eingeschränkter Download]
[ sddtf94-0e-vx3030-pbit.pdf, 846.06 KB, Sep.11.2017 ]
EZ3-VX3030 Quick Start
[eingeschränkter Download]
[ sddtf76-ez3-vx3030.pdf, 131.62 KB, Sep.11.2017 ]
EZ3-VX3030 Getting Started
[eingeschränkter Download]
[ sddtf75-ez3-vx3030.pdf, 661.69 KB, Sep.11.2017 ]
PB-VX3-4xx -3U-VPX Rear Transition Module User's Guide
[eingeschränkter Download]
[ cadtb03-0e-pb-vx3-4xx.pdf, 1.12 MB, Sep.11.2017 ]
General Safety Instruction
[ general-safety-instructions.pdf, 628.88 KB, Aug.02.2024 ]
BIOS
BIOS for VX3030 (ID15247)
[eingeschränkter Download]
[ vx3030_id15247.bin, 4.19 MB, Apr.06.2017 ]
White Papers
VXFabric White Paper
[ whitepaper_en_vxfabric-v2-final.pdf, 5.87 MB, Nov.27.2013 ]
Release Notes
VX3030 Hardware Release Note
[eingeschränkter Download]
[ cadta88-2e-vx3030-hrn.pdf, 377.68 KB, Jan.13.2023 ]
PB-VX3-4xx Hardware Release Notes
[eingeschränkter Download]
[ cadtb04-0e-pb-vx3-4xx-hrn.pdf, 481.67 KB, Jan.13.2023 ]
Release Notes Fedora 12
[eingeschränkter Download]
[ sddtf72-3e-fedora12-vx6060-vx3030.pdf, 494.1 KB, Jul.26.2023 ]
Release Notes VxWorks 6.8 on VX3030
[eingeschränkter Download]
[ sddtg04-0e-vx3030.pdf, 790.32 KB, Jul.26.2023 ]
Release Notes Fedora 14
[eingeschränkter Download]
[ sddtf82-3e-fedora14-vm6050-vx6060-30-35.pdf, 868.54 KB, Sep.15.2021 ]
Fedora 25 for VME / VPX Boards
[eingeschränkter Download]
[ sddtg53-2e-fedora25.pdf, 731.28 KB, Jul.03.2018 ]
Services
Kontron Services Brochure
[ kontron-services-brochure.pdf, 8.9 MB, Dec.17.2020 ]
Zubehör
|
Nand Flash Modules
|
|
FDM-SATA | more |
